PA0511.101NLT Pulse

PA0511.101NLT Images

Please contact us for more photos of PA0511.101NLT

Part Number PA0511.101NLT
Manufacturer Pulse
Quantity in stock 546100 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Ind Power Bead Wirewound 120nH 20% 31A T R
Category Inductor
Family Inductor Surface Mount
ROHS Compliant Yes
MSL Level PA0511.101NLT
Datasheet download PA0511.101NLT.pdf
Request Quotation for PA0511.101NLT

PA0511.101NLT Specifications

Part Number PA0511.101NLT
Operating Temperature -40 to 130 °C
Product Dimensions 10.2 x 7 x 4.96 mm
Package/Case 10.2 X 7 X 4.96
Type Power Bead
Minimum Quality Factor
Maximum Self Resonant Frequency
Inductance
Impedance
Core Material
Rad Hard No
Technology Wirewound
Maximum DC Current
Maximum DC Resistance 390 uOhm
Tolerance 20 %
Product Depth 7 mm
Product Height 4.96 mm
Product Length 10.2 mm
Replacement Part Number PART-PA0511.101NLT
Weight Contact us
Country of Origin -
