Please contact us for more photos of P1167.103 NLT
| Part Number | P1167.103 NLT |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 729320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Power Shielded Wirewound 10uH 20% 100KHz 2A T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | P1167.103 NLT |
| Datasheet download |  P1167.103 NLT.pdf |
| Part Number | P1167.103 NLT |
|---|---|
| Technology | Wirewound |
| Tolerance | 20 % |
| Rad Hard | No |
| Max Processing Temp | 245 |
| Test Frequency | 100 kHz |
| Type | Power |
| Operating Temperature | -40 to 130 °C |
| Protection Style | Shielded |
| Lead Finish | Tin |
| Package/Case | 7.54 X 7.54 X 4.5 |
| Product Dimensions | 7.54 x 7.54 x 4.5 mm |
| Product Depth | 7.54 mm |
| Product Height | 4.5 mm |
| Product Length | 7.54 mm |
| Replacement Part Number | PART-P1167.103 NLT |
| Weight | Contact us |
| Country of Origin | - |
