Part Number | HX6096FNLT |
---|---|
Manufacturer | Pulse |
Quantity in stock | 347310 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Telecom Transformer 1:1 1:1 1500Vrms -1.2dB Surface Mount |
Category | Transformer |
Family | Telecom Transformer |
ROHS Compliant | Yes |
MSL Level | HX6096FNLT |
Datasheet download | ![]() |
Part Number | HX6096FNLT |
---|---|
Minimum Crosstalk | -50@1MHz dB |
Turns Ratio | 1:1/1:1 |
Pin Count | 24 |
Maximum OCL Inductance | 0.35(Min) mH |
Mounting | Surface Mount |
Minimum CMRR | -50@2MHz dB |
Maximum Isolation Voltage | 1500 Vrms |
MSL Level | 1 |
Maximum Insertion Loss | -1.2@100KHz dB |
Transformer Type | 1000Base-T Single Port Ethernet Magnetic Transformer |
Minimum Return Loss | -16@1MHz to 40MHz dB |
Operating Temperature | -40 to 85 °C |
Max Processing Temp | 245 |
Rad Hard | No |
Product Dimensions | 18.161 x 15.113 x 6.35 |
Lead Style | L Lead |
Product Depth | 15.113 mm |
Product Height | 6.35 mm |
Product Length | 18.161 mm |
Replacement Part Number | PART-HX6096FNLT |
Weight | Contact us |
Country of Origin | - |
