Please contact us for more photos of E5288-R10B45-L
| Part Number | E5288-R10B45-L |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 719680 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn RJ-45 F 8 POS 1.27mm Solder ST Thru-Hole 8 Terminal 1 Port |
| Category | Connectors |
| Family | Connector Telephone and Telecom |
| ROHS Compliant | Yes |
| MSL Level | E5288-R10B45-L |
| Datasheet download |  E5288-R10B45-L.pdf |
| Part Number | E5288-R10B45-L |
|---|---|
| Type | RJ-45 |
| Number of Terminals | 8 |
| Termination Method | Solder |
| Pin Count | 8 |
| Lead Finish | Tin Over Nickel |
| Body Orientation | Straight |
| Number of Ports | 1 |
| Number of Contacts | 8 |
| Package Dimensions | 16 x 16.7 x 16.5 mm |
| Mounting | Through Hole |
| Housing Material | FR52 |
| Operating Temperature | 0 to 70 °C |
| Rad Hard | No |
| Gender | F |
| Maximum Processing Temperature | 265 °C |
| Contact Material | Phosphor Bronze |
| Pitch | 1.27 mm |
| Contact Plating | Gold Over Nickel |
| Product Depth | 16.7 mm |
| Product Height | 16.5 mm |
| Product Length | 16 mm |
| Replacement Part Number | PART-E5288-R10B45-L |
| Weight | Contact us |
| Country of Origin | - |
