2309A-1HPGG Integrated Device Technology

2309A-1HPGG Images

Please contact us for more photos of 2309A-1HPGG

Part Number	2309A-1HPGG
Manufacturer	Integrated Device Technology
Quantity in stock	601540 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	3.3V Zero Delay Clock Buffer
Category	RF & Microwave
Family	RF ICs
ROHS Compliant	Yes
MSL Level	2309A-1HPGG
Datasheet download	2309A-1HPGG.pdf

Request Quotation for 2309A-1HPGG

2309A-1HPGG Specifications

Part Number	2309A-1HPGG
Moisture Sensitivity Level	1
Number of Elements per Chip	1
Type	Zero Delay PLL Clock Buffer
Product Dimensions	5 x 4.4 x 1 mm
Max Processing Temp	260
Screening Level	Commercial
Operating Temperature	0 to 70 °C
Output Frequency Range	10 to 133 MHz
Rad Hard	No
Mounting	Surface Mount
Operating Supply Voltage	3.3 V
Pitch	0.65
Pin Count	16
MSL Level	1
Supplier Package	TSSOP
Lead Finish	Matte Tin
Package	16TSSOP
Replacement Part Number	PART-2309A-1HPGG
Weight	Contact us
Country of Origin	-
