Please contact us for more photos of BAP50-04,215
| Part Number | BAP50-04,215 |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 448720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode PIN 50V 3-Pin TO-236AB T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAP50-04,215 |
| Datasheet download |  BAP50-04,215.pdf |
| Part Number | BAP50-04,215 |
|---|---|
| Pin Count | 3 |
| Rad Hard | No |
| Product Dimensions | 3 x 1.4 x 1 mm |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Maximum Series Resistance @ Maximum IF | 5@10mA Ohm |
| Configuration | Dual Series |
| Maximum Diode Capacitance | 0.5@5V pF |
| Supplier Package | TO-236AB |
| Maximum Power Dissipation | 250 mW |
| Maximum Forward Current | 50 mA |
| Max Processing Temp | 260 |
| Typical Carrier Life Time | 1.05 us |
| Maximum Forward Voltage | 1.1 V |
| Maximum Reverse Voltage | 50 V |
| Maximum Series Resistance @ Minimum IF | [email protected] Ohm |
| Package | 3TO-236AB |
| Replacement Part Number | PART-BAP50-04,215 |
| Weight | Contact us |
| Country of Origin | - |
