Please contact us for more photos of EXB28V473JX
| Part Number | EXB28V473JX |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 853540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film Array 47K Ohm 5% \u00b1200ppm \u00b0C ISOL Molded 8-Pin 0804(4 X 0402) Convex SMD Punched Carrier T R |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | EXB28V473JX |
| Datasheet download |  EXB28V473JX.pdf |
| Part Number | EXB28V473JX |
|---|---|
| Mounting | Surface Mount |
| Technology | Thick Film |
| Lead Finish | Tin |
| Operating Temperature | -55 to 125 °C |
| Resistance Value | 47 kOhm |
| Power Rating per Resistor | 1/32 W |
| Temperature Coefficient | ±200 ppm/°C |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Terminal Pitch | 0.5 mm |
| Tolerance | 5 % |
| Case Style | Molded |
| Case Size | 0804 |
| Termination Style | Convex |
| Product Dimensions | 2 x 1 x 0.35 mm |
| Product Depth | 1 mm |
| Product Height | 0.35 mm |
| Product Length | 2 mm |
| Product Weight | 2 mg |
| Replacement Part Number | PART-EXB28V473JX |
| Weight | Contact us |
| Country of Origin | - |
