EVM2WSX80B16 Panasonic

EVM2WSX80B16 Images

Please contact us for more photos of EVM2WSX80B16

Part Number EVM2WSX80B16
Manufacturer Panasonic
Quantity in stock 591650 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Res Cermet Trimmer 1M Ohm 25% 3 20W 1Turn (2.2 X 2.75 X 1.05mm) Foot Print SMD Carrier T R
Category Resistor
Family Resistor Trimmers, Potentiometers and Rheostats
ROHS Compliant Yes
MSL Level EVM2WSX80B16
Datasheet download EVM2WSX80B16.pdf
Request Quotation for EVM2WSX80B16

EVM2WSX80B16 Specifications

Part Number EVM2WSX80B16
Tolerance 25 %
Power Rating 0.15 W
Type Trimmer
Temperature Coefficient ±250 ppm
Rad Hard No
Package Type Surface Mount/Foot Print
Termination Style Foot Print
Resistance Value 1 MOhm
Mounting Surface Mount
Technology Cermet
Lead Finish Tin
Number of Turns 1 Turns
Product Dimensions 2.2 x 2.75 x 1.05 mm
Product Depth 2.75 mm
Product Height 1.05 mm
Product Length 2.2 mm
Replacement Part Number PART-EVM2WSX80B16
Weight Contact us
Country of Origin -
