Part Number | ELC10E391L |
---|---|
Manufacturer | Panasonic |
Quantity in stock | 200710 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Ind Choke Shielded Wirewound 390uH 10% 10KHz Ferrite 500mA RDL |
Category | Inductor |
Family | Inductor Leaded |
ROHS Compliant | Yes |
MSL Level | ELC10E391L |
Datasheet download | ![]() |
Part Number | ELC10E391L |
---|---|
Lead Style | Radial |
Protection Style | Shielded |
Package/Case | 10 X 13 |
Test Frequency | 10 kHz |
Product Dimensions | 13 mm |
Technology | Wirewound |
Rad Hard | No |
Tolerance | 10 % |
Lead Finish | Tin/Copper |
Max Processing Temp | 260 |
Product Diameter | 10 mm |
Product Height | 13 mm |
Replacement Part Number | PART-ELC10E391L |
Weight | Contact us |
Country of Origin | - |
