Please contact us for more photos of EEHZA1J220XP
| Part Number | EEHZA1J220XP |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 132730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 22uF 63V 20% (6.3 X 7.7mm) SMD 0.08 Ohm 1500mA 5000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEHZA1J220XP |
| Datasheet download |  EEHZA1J220XP.pdf |
| Part Number | EEHZA1J220XP |
|---|---|
| Mounting | Surface Mount |
| Capacitance Value | 22 uF |
| Construction | Cylindrical |
| Package/Case | 6.3 X 7.7 |
| Rad Hard | No |
| Tolerance | 20 % |
| Ripple Current | 1500 mA |
| Leakage Current | 13.86@2Min uA |
| Product Dimensions | 7.7 mm |
| Voltage(DC) | 63 V |
| Equivalent Series Resistance | 0.08 Ohm |
| Operating Temperature | -55 to 105 °C |
| Product Diameter | 6.3 mm |
| Product Height | 7.7 mm |
| Replacement Part Number | PART-EEHZA1J220XP |
| Weight | Contact us |
| Country of Origin | - |
