Please contact us for more photos of EEFCX1E150R
| Part Number | EEFCX1E150R |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 417510 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 15uF 25V 20% 2917 J Lead Flat 0.04 Ohm3000mA 1000 hr 105\u00b0C Embossed Carrier T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEFCX1E150R |
| Datasheet download |  EEFCX1E150R.pdf |
| Part Number | EEFCX1E150R |
|---|---|
| Capacitance Value | 15 uF |
| Ripple Current | 3000 mA |
| Equivalent Series Resistance | 0.04 Ohm |
| Construction | Flat |
| Mounting | Surface Mount |
| Operating Temperature | -40 to 105 °C |
| Lead Finish | Tin |
| Supplier Package | 2917 |
| Leakage Current | 112.5@2Min uA |
| Voltage(DC) | 25 V |
| Product Dimensions | 7.3 x 4.3 x 1.9 |
| Package/Case | 2917 |
| Tolerance | 20 % |
| Termination Style | J-Lead |
| Pin Count | 2 |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Product Depth | 4.3 mm |
| Product Height | 1.9 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-EEFCX1E150R |
| Weight | Contact us |
| Country of Origin | - |
