Please contact us for more photos of EEFCS1V100R
| Part Number | EEFCS1V100R |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 749650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 10uF 35V 20% 2917 J Lead Flat 0.04 Ohm 3200mA 2000 hr 105\u00b0C Embossed T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEFCS1V100R |
| Datasheet download |  EEFCS1V100R.pdf |
| Part Number | EEFCS1V100R |
|---|---|
| Equivalent Series Resistance | 0.04 Ohm |
| Construction | Flat |
| Mounting | Surface Mount |
| Max Processing Temp | 240 |
| Product Dimensions | 7.3 x 4.3 x 1.1 |
| Ripple Current | 3200 mA |
| Lead Finish | Tin |
| Termination Style | J Lead |
| Capacitance Value | 10 uF |
| Voltage(DC) | 35 V |
| Leakage Current | 105@2Min uA |
| Operating Temperature | -55 to 105 °C |
| Rad Hard | No |
| Tolerance | 20 % |
| Pin Count | 2 |
| Supplier Package | 2917 |
| Package/Case | 2917 |
| Product Depth | 4.3 mm |
| Product Height | 1.1 mm |
| Product Length | 7.3 mm |
| Replacement Part Number | PART-EEFCS1V100R |
| Weight | Contact us |
| Country of Origin | - |
