Please contact us for more photos of EEEHAC470WAR
| Part Number | EEEHAC470WAR |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 438510 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 47uF 16V 20% (5 X 5.4mm) SMD 39mA 1000 hr 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEEHAC470WAR |
| Datasheet download |  EEEHAC470WAR.pdf |
| Part Number | EEEHAC470WAR |
|---|---|
| Lead Finish | Tin/Bismuth |
| Product Dimensions | 5.4 mm |
| Package/Case | 5 X 5.4 |
| Rad Hard | No |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Leakage Current | 7.52@2Min uA |
| Ripple Current | 39 mA |
| Mounting | Surface Mount |
| Construction | Cylindrical |
| Capacitance Value | 47 uF |
| Operating Temperature | -40 to 105 °C |
| Voltage(DC) | 16 V |
| Product Diameter | 5 mm |
| Product Height | 5.4 mm |
| Replacement Part Number | PART-EEEHAC470WAR |
| Weight | Contact us |
| Country of Origin | - |
