Please contact us for more photos of EEEFT1E220AR
| Part Number | EEEFT1E220AR |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 782790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 22uF 25V 20% (4 X 5.8mm) SMD 0.85 Ohm 160mA 2000 hr 105\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEEFT1E220AR |
| Datasheet download |  EEEFT1E220AR.pdf |
| Part Number | EEEFT1E220AR |
|---|---|
| Lead Finish | Tin/Bismuth |
| Operating Temperature | -55 to 105 °C |
| Equivalent Series Resistance | 0.85 Ohm |
| Voltage(DC) | 25 V |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Leakage Current | 5.5@2Min uA |
| Product Dimensions | 5.8 mm |
| Mounting | Surface Mount |
| Package/Case | 4 X 5.8 |
| Ripple Current | 160 mA |
| Capacitance Value | 22 uF |
| Construction | Cylindrical |
| Lifetime | 2000 hr |
| Product Diameter | 4 mm |
| Product Height | 5.8 mm |
| Replacement Part Number | PART-EEEFT1E220AR |
| Weight | Contact us |
| Country of Origin | - |
