Please contact us for more photos of EEE2AA220P
| Part Number | EEE2AA220P |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 782300 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 22uF 100V 20% (10 X 10.2mm) SMD 85mA 2000 hr 85\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEE2AA220P |
| Datasheet download |  EEE2AA220P.pdf |
| Part Number | EEE2AA220P |
|---|---|
| Lead Finish | Tin/Bismuth |
| Voltage(DC) | 100 V |
| Product Dimensions | 10.2 mm |
| Ripple Current | 85 mA |
| Max Processing Temp | 235 |
| Tolerance | 20 % |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Leakage Current | 22@2Min uA |
| Mounting | Surface Mount |
| Construction | Cylindrical |
| Capacitance Value | 22 uF |
| Package/Case | 10 X 10.2 |
| Product Diameter | 10 mm |
| Product Height | 10.2 mm |
| Replacement Part Number | PART-EEE2AA220P |
| Weight | Contact us |
| Country of Origin | - |
