Please contact us for more photos of ECWU2823V16
| Part Number | ECWU2823V16 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 293840 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.082uF 250V PEN 5% (6 X 5 X 3.2mm) SMD 85\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | ECWU2823V16 |
| Datasheet download |  ECWU2823V16.pdf |
| Part Number | ECWU2823V16 |
|---|---|
| Capacitance Value | 0.082 uF |
| Package/Case | 2420 |
| Lead Finish | Tin/Silver/Copper |
| Rad Hard | No |
| Operating Temperature | -55 to 85 °C |
| Tolerance | 5 % |
| Product Dimensions | 6 x 5 x 3.2 mm |
| Construction | Flat |
| Mounting | Surface Mount |
| Max Processing Temp | 240 |
| Type | Flat |
| Voltage(DC) | 250 V |
| Dielectric | PEN |
| Case Size | 2420 |
| Product Depth | 5 mm |
| Product Height | 3.2 mm |
| Product Length | 6 mm |
| Replacement Part Number | PART-ECWU2823V16 |
| Weight | Contact us |
| Country of Origin | - |
