ECPU1C105MA5 Panasonic

ECPU1C105MA5 Images

Please contact us for more photos of ECPU1C105MA5

Part Number ECPU1C105MA5
Manufacturer Panasonic
Quantity in stock 232950 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Cap Film 1uF 16V 20% (3.2 X 2.5 X 1.4mm) SMD 85\u00b0C T R
Category Capacitors
Family Capacitor Film
ROHS Compliant Yes
MSL Level ECPU1C105MA5
Datasheet download ECPU1C105MA5.pdf
Request Quotation for ECPU1C105MA5

ECPU1C105MA5 Specifications

Part Number ECPU1C105MA5
Product Dimensions 3.2 x 2.5 x 1.4 mm
Lead Finish Tin/Silver/Copper
Package/Case 1210
Operating Temperature -40 to 85 °C
Tolerance 20 %
Rad Hard No
Case Size 1210
Construction Flat
Mounting Surface Mount
Voltage(DC) 16 V
Capacitance Value 1 uF
Max Processing Temp 240
Product Depth 2.5 mm
Product Height 1.4 mm
Product Length 3.2 mm
Replacement Part Number PART-ECPU1C105MA5
Weight Contact us
Country of Origin -
