ECA1EHG470B Panasonic

ECA1EHG470B Images

Please contact us for more photos of ECA1EHG470B

Part Number ECA1EHG470B
Manufacturer Panasonic
Quantity in stock 188090 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Cap Aluminum 47uF 25V 20% (5 X 11mm) Radial Aluminum Cylindrical Can 5mm 91mA 1000 hr 105\u00b0C Ammo Pack
Category Capacitors
Family Capacitor Aluminum
ROHS Compliant Yes
MSL Level ECA1EHG470B
Datasheet download ECA1EHG470B.pdf
Request Quotation for ECA1EHG470B

ECA1EHG470B Specifications

Part Number ECA1EHG470B
Voltage(DC) 25 V
Termination Style Radial
Rad Hard No
Tolerance 20 %
Operating Temperature -55 to 105 °C
Package/Case 5 X 11
Leakage Current 11.75@2Min uA
Product Dimensions 11 mm
Construction Aluminum Cylindrical Can
Max Processing Temp 250 to 260
Mounting Through Hole
Ripple Current 91 mA
Lead Pitch For Radial 5 mm
Lead Finish Tin
Capacitance Value 47 uF
Product Diameter 5 mm
Product Height 11 mm
Replacement Part Number PART-ECA1EHG470B
Weight Contact us
Country of Origin -
