Please contact us for more photos of ECA1CM102B
| Part Number | ECA1CM102B |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 571310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 1000uF 16V 20% (10 X 16mm) Radial Aluminum Cylindrical Can 5mm 680mA 2000 hr 85\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | ECA1CM102B |
| Datasheet download |  ECA1CM102B.pdf |
| Part Number | ECA1CM102B |
|---|---|
| Capacitance Value | 1000 uF |
| Construction | Aluminum Cylindrical Can |
| Max Processing Temp | 250 to 260 |
| Lead Finish | Tin |
| Voltage(DC) | 16 V |
| Mounting | Through Hole |
| Lead Pitch For Radial | 5 mm |
| Product Dimensions | 16 mm |
| Ripple Current | 680 mA |
| Package/Case | 10 X 16 |
| Termination Style | Radial |
| Rad Hard | No |
| Tolerance | 20 % |
| Operating Temperature | -40 to 85 °C |
| Leakage Current | 160@2Min uA |
| Product Diameter | 10 mm |
| Product Height | 16 mm |
| Replacement Part Number | PART-ECA1CM102B |
| Weight | Contact us |
| Country of Origin | - |
