Please contact us for more photos of AXK6S34447YG
| Part Number | AXK6S34447YG |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 279880 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board to Board HDR 34 POS 0.5mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | AXK6S34447YG |
| Datasheet download |  AXK6S34447YG.pdf |
| Part Number | AXK6S34447YG |
|---|---|
| Maximum Contact Resistance | 80 MOhm |
| Termination Method | Solder |
| Maximum Voltage Rating | 60|60 Vdc|Vac |
| Pin Count | 34 |
| Maximum Processing Temperature | 260 °C |
| Gender | HDR |
| Mounting | Surface Mount |
| Housing Material | Heat Resistant Resin |
| Body Orientation | Straight |
| Type | Board to Board |
| Pitch | 0.5 mm |
| Maximum Current Rating | 0.5/Contact A |
| Number of Contacts | 34 |
| Package Dimensions | 11.7 x 5 x 3.3 mm |
| Rad Hard | No |
| Operating Temperature | -55 to 85 °C |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Number of Rows | 2 |
| Lead Finish | Gold Over Nickel |
| Product Depth | 5 mm |
| Product Height | 3.3 mm |
| Product Length | 11.7 mm |
| Replacement Part Number | PART-AXK6S34447YG |
| Weight | Contact us |
| Country of Origin | - |
