Please contact us for more photos of AXE516124AW1
| Part Number | AXE516124AW1 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 211010 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | A4S CONNECTOR SOCKET AW1 |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | AXE516124AW1 |
| Datasheet download |  AXE516124AW1.pdf |
| Part Number | AXE516124AW1 |
|---|---|
| Family | AXE |
| Maximum Contact Resistance | 60 MOhm |
| Contact Plating | Gold Over Nickel |
| Contact Material | Copper Alloy |
| Operating Temperature | -55 to 85 °C |
| Number of Rows | 2 |
| Gender | SKT |
| Rad Hard | No |
| Housing Material | Liquid Crystal Polymer |
| Mounting | Surface Mount |
| Termination Method | Solder |
| Packaging | Embossed Tape and Reel |
| Number of Contacts | 16 |
| Maximum Voltage Rating | 60|60 Vdc|Vac |
| Maximum Current Rating | 0.3/Contact A |
| Type | Board to Board |
| Pitch | 0.4 mm |
| Lead Free | Yes |
| Body Orientation | Straight |
| Product Depth | 2.2 mm |
| Product Height | 0.77 mm |
| Product Length | 5.7 mm |
| Replacement Part Number | PART-AXE516124AW1 |
| Weight | Contact us |
| Country of Origin | - |
