Part Number | S9S08QD2J1CSCR |
---|---|
Manufacturer | NXP |
Quantity in stock | 638690 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | MCU 8-bit HCS08 CISC 2KB Flash 3.3V 5V 8-Pin SOIC N T R |
Category | Microcontrollers MCU IC |
Family | 8 Bit Microcontrollers MCU |
ROHS Compliant | Yes |
MSL Level | S9S08QD2J1CSCR |
Datasheet download | ![]() |
Part Number | S9S08QD2J1CSCR |
---|---|
Minimum Operating Supply Voltage | 2.7 V |
Maximum Speed | 8 MHz |
Program Memory Type | Flash |
Data Bus Width | 8 Bit |
On-Chip ADC | 4-chx10-bit |
Pin Count | 8 |
Instruction Set Architecture | CISC |
Watchdog | 1 |
Product Dimensions | 5 x 4 x 1.5 mm |
Number of Timers | 3 |
RAM Size | 128 byte |
Number of Programmable I/Os | 4 |
Program Memory Size | 2 KB |
Lead Finish | Matte Tin |
Maximum Expanded Memory Size | 64 KB |
Rad Hard | No |
Operating Supply Voltage | 3.3|5 V |
Mounting | Surface Mount |
MSL Level | 3 |
Maximum Operating Supply Voltage | 5.5 V |
Operating Temperature | -40 to 85 °C |
Supplier Package | SOIC N |
Max Processing Temp | 260 |
Package | 8SOIC N |
Replacement Part Number | PART-S9S08QD2J1CSCR |
Weight | Contact us |
Country of Origin | - |
