Please contact us for more photos of S9KEAZN32AMLC
| Part Number | S9KEAZN32AMLC |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 836790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit KEA64 ARM Cortex M0+ RISC 32KB Flash 3.3V 5V 32-Pin LQFP Brick |
| Category | Microcontrollers MCU IC |
| Family | ARM Based Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | S9KEAZN32AMLC |
| Datasheet download |  S9KEAZN32AMLC.pdf |
| Part Number | S9KEAZN32AMLC |
|---|---|
| Minimum Operating Supply Voltage | 2.7 V |
| Program Memory Type | Flash |
| Watchdog | 1 |
| Data Memory Size | 256 byte |
| Number of Timers | 4 |
| Supplier Package | LQFP |
| Lead Finish | Matte Tin |
| Screening Level | Automotive |
| On-Chip ADC | 16-chx12-bit |
| Number of Programmable I/Os | 28 |
| Interface Type | I2C/SPI/UART |
| RAM Size | 4 KB |
| Product Dimensions | 7 x 7 x 1.4 |
| Rad Hard | No |
| Instruction Set Architecture | RISC |
| Mounting | Surface Mount |
| Operating Supply Voltage | 3.3|5 V |
| Device Core | ARM Cortex M0+ |
| Max Processing Temp | 260 |
| Analog Comparators | 2 |
| Data Bus Width | 32 Bit |
| Pin Count | 32 |
| Operating Temperature | -40 to 125 °C |
| Program Memory Size | 32 KB |
| MSL Level | 3 |
| Maximum Speed | 40 MHz |
| Maximum Operating Supply Voltage | 5.5 V |
| Package | 32LQFP |
| Replacement Part Number | PART-S9KEAZN32AMLC |
| Weight | Contact us |
| Country of Origin | - |
