Please contact us for more photos of MCIMX6X3EVN10AB
| Part Number | MCIMX6X3EVN10AB |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 369550 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MPU i.MX 6 RISC 32-Bit 800MHz 166MHz 1.8V 2.5V 2.8V 3.15V 400-Pin MAPBGA Tray |
| Category | Processor IC |
| Family | Processors |
| ROHS Compliant | Yes |
| MSL Level | MCIMX6X3EVN10AB |
| Datasheet download |  MCIMX6X3EVN10AB.pdf |
| Part Number | MCIMX6X3EVN10AB |
|---|---|
| Operating Supply Voltage | 1.5 V |
| I/O Voltage | 1.8|2.5|2.8|3.15 V |
| Operating Temperature | -20 to 105 °C |
| Program Memory Size | 12 KB |
| RAM Size | 176 KB |
| Fabrication Technology | 0.04um |
| Product Dimensions | 17 x 17 x 1.2(Max) |
| Number of CPU Cores | 2 |
| Lead Finish | Tin|Silver|Copper |
| Instruction Set Architecture | RISC |
| Device Core | ARM Cortex A9|ARM Cortex M4 |
| Rad Hard | No |
| Interface Type | CAN/Ethernet/I2C/PCIe/SPI/UART/USB |
| Maximum Speed | 800|166 MHz |
| MSL Level | 3 |
| Max Processing Temp | 260 |
| Data Bus Width | 32 Bit |
| Pin Count | 400 |
| Supplier Package | MAPBGA |
| Mounting | Surface Mount |
| Package | 400MAPBGA |
| Replacement Part Number | PART-MCIMX6X3EVN10AB |
| Weight | Contact us |
| Country of Origin | - |
