| Part Number | MC9S12XD256CAL |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 477800 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 16-bit HCS12X CISC 256KB Flash 2.5V 5V 112-Pin LQFP Brick |
| Category | Microcontrollers MCU IC |
| Family | 16 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MC9S12XD256CAL |
| Datasheet download |  MC9S12XD256CAL.pdf |
| Part Number | MC9S12XD256CAL |
|---|---|
| Interface Type | CAN/I2C/SCI/SPI |
| Watchdog | 1 |
| Program Memory Size | 256 KB |
| Supplier Package | LQFP |
| Minimum Operating Supply Voltage | 2.35|3.15 V |
| Maximum Expanded Memory Size | 4 MB |
| Number of Programmable I/Os | 91 |
| Instruction Set Architecture | CISC |
| RAM Size | 14 KB |
| Data Bus Width | 16 Bit |
| Pin Count | 112 |
| Program Memory Type | Flash |
| Maximum Operating Supply Voltage | 2.75|5.5 V |
| Lead Finish | Matte Tin |
| Operating Supply Voltage | 2.5|5 V |
| Rad Hard | No |
| Product Dimensions | 20 x 20 x 1.45 mm |
| Number of Timers | 12 |
| Mounting | Surface Mount |
| Maximum Speed | 80 MHz |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| MSL Level | 3 |
| On-Chip ADC | 2(8-chx10-bit) |
| Package | 112LQFP |
| Replacement Part Number | PART-MC9S12XD256CAL |
| Weight | Contact us |
| Country of Origin | - |
