| Part Number | MC9S08SH4CTJ |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 422370 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 8-bit HCS08 CISC 4KB Flash 3.3V 5V 20-Pin TSSOP Rail |
| Category | Microcontrollers MCU IC |
| Family | 8 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MC9S08SH4CTJ |
| Datasheet download |  MC9S08SH4CTJ.pdf |
| Part Number | MC9S08SH4CTJ |
|---|---|
| Minimum Operating Supply Voltage | 2.7 V |
| Data Bus Width | 8 Bit |
| On-Chip ADC | 12-chx10-bit |
| Program Memory Type | Flash |
| Number of Timers | 1 |
| Watchdog | 1 |
| Pin Count | 20 |
| Program Memory Size | 4 KB |
| Instruction Set Architecture | CISC |
| RAM Size | 256 byte |
| Interface Type | I2C/SCI/SPI |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Product Dimensions | 6.6 x 4.5 x 1.05 mm |
| Maximum Expanded Memory Size | 64 KB |
| Operating Supply Voltage | 3.3|5 V |
| Mounting | Surface Mount |
| Operating Temperature | -40 to 85 °C |
| Number of Programmable I/Os | 17 |
| Max Processing Temp | 260 |
| Supplier Package | TSSOP |
| MSL Level | 3 |
| Analog Comparators | 1 |
| Maximum Speed | 40 MHz |
| Maximum Operating Supply Voltage | 5.5 V |
| Package | 20TSSOP |
| Replacement Part Number | PART-MC9S08SH4CTJ |
| Weight | Contact us |
| Country of Origin | - |
