MC68302CEH16C NXP

MC68302CEH16C Images

Please contact us for more photos of MC68302CEH16C

Part Number MC68302CEH16C
Manufacturer NXP
Quantity in stock 681360 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description MPU M68000 RISC 32-Bit HCMOS 16MHz 132-Pin PQFP Tray
Category Processor IC
Family Processors
ROHS Compliant Yes
MSL Level MC68302CEH16C
Datasheet download MC68302CEH16C.pdf
Request Quotation for MC68302CEH16C

MC68302CEH16C Specifications

Part Number MC68302CEH16C
Lead Finish Matte Tin
Rad Hard No
Mounting Surface Mount
Maximum Speed 16 MHz
Data Bus Width 32 Bit
Number of CPU Cores 1
MSL Level 3
Supplier Package PQFP
Instruction Set Architecture RISC
Fabrication Technology HCMOS
Operating Supply Voltage 5 V
Device Core ColdFire
Pin Count 132
Operating Temperature -40 to 85 °C
Product Dimensions 46.13 x 46.13 x 4.9 mm
Max Processing Temp 260
Package 132PQFP
Replacement Part Number PART-MC68302CEH16C
Weight Contact us
Country of Origin -
