Please contact us for more photos of MC56F8335VFGE
| Part Number | MC56F8335VFGE |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 632680 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 16-bit MC56F83xx CISC 64KB Flash 3.3V 128-Pin LQFP Tray |
| Category | Microcontrollers MCU IC |
| Family | 16 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | MC56F8335VFGE |
| Datasheet download |  MC56F8335VFGE.pdf |
| Part Number | MC56F8335VFGE |
|---|---|
| Maximum Operating Supply Voltage | 3.6 V |
| Number of Programmable I/Os | 49 |
| Minimum Operating Supply Voltage | 3 V |
| Supplier Package | LQFP |
| Number of Timers | 4 |
| Instruction Set Architecture | CISC |
| Lead Finish | Matte Tin |
| Product Dimensions | 20 x 14 x 1.4 mm |
| Data Bus Width | 16 Bit |
| Special Features | CAN Controller |
| Interface Type | CAN/SCI/SPI |
| Pin Count | 128 |
| Rad Hard | No |
| On-Chip ADC | 4(4-chx12-bit) |
| Mounting | Surface Mount |
| Program Memory Size | 64 KB |
| Operating Supply Voltage | 3.3 V |
| Program Memory Type | Flash |
| Max Processing Temp | 260 |
| Maximum Speed | 60 MHz |
| Operating Temperature | -40 to 105 °C |
| MSL Level | 3 |
| RAM Size | 12 KB |
| Package | 128LQFP |
| Replacement Part Number | PART-MC56F8335VFGE |
| Weight | Contact us |
| Country of Origin | - |
