EKY-101ELL560MH20D Nippon ChemiCon

EKY-101ELL560MH20D Images

Please contact us for more photos of EKY-101ELL560MH20D

Part Number EKY-101ELL560MH20D
Manufacturer Nippon ChemiCon
Quantity in stock 247470 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Cap Aluminum 56uF 100V \u00b120% (8 X 20mm) Radial Aluminum Cylindrical Can 3.5mm 565mA 7000hr 105\u00b0C Bulk
Category Capacitors
Family Capacitor Aluminum
ROHS Compliant Yes
MSL Level EKY-101ELL560MH20D
Datasheet download EKY-101ELL560MH20D.pdf
Request Quotation for EKY-101ELL560MH20D

EKY-101ELL560MH20D Specifications

Part Number EKY-101ELL560MH20D
Mounting Through Hole
Termination Style Radial
Pin Count 2
Lifetime 7000 hr
Lead Finish Tin|Bismuth
Maximum Processing Temperature 260 °C
Rad Hard No
Supplier Package Radial
Ripple Current 565 mA
Package/Case 8 X 20
Package Dimensions 8 x 20 mm
Construction Aluminum Cylindrical Can
Operating Temperature -40 to 105 °C
Leakage Current 56@2Min uA
Voltage(DC) 100 Vdc
Lead Pitch For Radial 3.5 mm
Tolerance ±20 %
Capacitance Value 56 uF
Product Diameter 8 mm
Product Height 20 mm
Replacement Part Number PART-EKY-101ELL560MH20D
Weight Contact us
Country of Origin -
