Please contact us for more photos of UPW1H100MDD1TD
| Part Number | UPW1H100MDD1TD |
|---|---|
| Manufacturer | Nichicon |
| Quantity in stock | 280420 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 10uF 50V 20% (5 X 11mm) Radial Aluminum Cylindrical Can 2mm 46mA 1000 hr 105\u00b0C Ammo Pack |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | UPW1H100MDD1TD |
| Datasheet download |  UPW1H100MDD1TD.pdf |
| Part Number | UPW1H100MDD1TD |
|---|---|
| Leakage Current | 15@1Min|5@2Min uA |
| Lead Finish | Matte Tin |
| Construction | Aluminum Cylindrical Can |
| Mounting | Through Hole |
| Capacitance Value | 10 uF |
| Operating Temperature | -55 to 105 °C |
| Package/Case | 8 X 11.5 |
| Lead Pitch For Radial | 2 mm |
| Product Dimensions | 11.5 mm |
| Voltage(DC) | 50 V |
| Rad Hard | No |
| Termination Style | Radial |
| Tolerance | 20 % |
| Max Processing Temp | 260 |
| Ripple Current | 46 mA |
| Product Diameter | 8 mm |
| Product Height | 11.5 mm |
| Replacement Part Number | PART-UPW1H100MDD1TD |
| Weight | Contact us |
| Country of Origin | - |
