Please contact us for more photos of TVX1A222MCD
| Part Number | TVX1A222MCD |
|---|---|
| Manufacturer | Nichicon |
| Quantity in stock | 602260 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 2200uF 10V 20% (13 X 26mm) Axial 1090mA 2000 hr 85\u00b0C |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | TVX1A222MCD |
| Datasheet download |  TVX1A222MCD.pdf |
| Part Number | TVX1A222MCD |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 26 mm |
| Leakage Current | 4@1Min|3@2Min uA |
| Voltage(DC) | 10 V |
| Ripple Current | 1090 mA |
| Mounting | Through Hole |
| Capacitance Value | 2200 uF |
| Termination Style | Axial |
| Package/Case | 13 X 26 |
| Tolerance | 20 % |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Product Diameter | 13 mm |
| Product Length | 26 mm |
| Replacement Part Number | PART-TVX1A222MCD |
| Weight | Contact us |
| Country of Origin | - |
