Please contact us for more photos of NMC1206NPO220J50TRPLPF
| Part Number | NMC1206NPO220J50TRPLPF |
|---|---|
| Manufacturer | NIC Components |
| Quantity in stock | 557060 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 22pF 50VDC C0G 5% SMD 1206 125\u00b0C Emboss T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | NMC1206NPO220J50TRPLPF |
| Datasheet download |  NMC1206NPO220J50TRPLPF.pdf |
| Part Number | NMC1206NPO220J50TRPLPF |
|---|---|
| Pin Count | 2 |
| Tolerance | 5 % |
| Construction | Flat |
| Case Style | Ceramic Chip |
| Capacitance Value | 22 pF |
| Voltage(DC) | 50 V |
| Case Size | 1206 |
| Lead Finish | Matte Tin Over Nickel |
| Termination Style | Wraparound |
| Rad Hard | No |
| Package/Case | 1206 |
| Mounting | Surface Mount |
| Package Dimensions | 3.2 x 1.6 x 1.8 mm |
| Supplier Package | 1206 |
| Maximum Processing Temperature | 260 °C |
| Moisture Sensitivity Level | 1 |
| Dielectric | C0G |
| Operating Temperature | -55 to 125 °C |
| Product Depth | 1.6 mm |
| Product Height | 1.8 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-NMC1206NPO220J50TRPLPF |
| Weight | Contact us |
| Country of Origin | - |
