Please contact us for more photos of NMC0402X7R683K16TRPF
| Part Number | NMC0402X7R683K16TRPF |
|---|---|
| Manufacturer | NIC Components |
| Quantity in stock | 328030 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.068uF 16V X7R 10% SMD 0402 125\u00b0C Punched Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | NMC0402X7R683K16TRPF |
| Datasheet download |  NMC0402X7R683K16TRPF.pdf |
| Part Number | NMC0402X7R683K16TRPF |
|---|---|
| Case Style | Ceramic Chip |
| Dielectric | X7R |
| Capacitance Value | 0.068 uF |
| Termination Style | Wraparound |
| Construction | Flat |
| Supplier Package | 0402 |
| Product Dimensions | 1 x 0.5 x 0.6(Max) |
| Package/Case | 0402 |
| Pin Count | 2 |
| Lead Finish | Matte Tin Over Nickel |
| Rad Hard | No |
| Operating Temperature | -55 to 125 °C |
| Tolerance | 10 % |
| MSL Level | 1 |
| Case Size | 0402 |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Voltage(DC) | 16 V |
| Product Depth | 0.5 mm |
| Product Height | 0.6(Max) mm |
| Product Length | 1 mm |
| Replacement Part Number | PART-NMC0402X7R683K16TRPF |
| Weight | Contact us |
| Country of Origin | - |
