Please contact us for more photos of MP1583DN-LF-Z
| Part Number | MP1583DN-LF-Z |
|---|---|
| Manufacturer | MPS |
| Quantity in stock | 356920 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conv DC-DC Single Step Down 4.75V to 23V 8-Pin SOIC EP T R |
| Category | Power Management IC |
| Family | DC to DC Converter |
| ROHS Compliant | Yes |
| MSL Level | MP1583DN-LF-Z |
| Datasheet download |  MP1583DN-LF-Z.pdf |
| Part Number | MP1583DN-LF-Z |
|---|---|
| Switching Frequency | 435 kHz |
| Switching Regulator | Yes |
| Operating Supply Voltage | 4.75 to 23 V |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Supplier Package | SOIC EP |
| Type | Step Down |
| Rad Hard | No |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Maximum Output Current | 3 A |
| Number of Outputs | 1 |
| Output Type | Adjustable |
| Minimum Input Voltage | 4.75 V |
| Efficiency | 95 % |
| Pin Count | 8 |
| Product Dimensions | 5 x 4 x 1.52 mm |
| MSL Level | 2a |
| Output Voltage | 1.22 to 21 V |
| Maximum Input Voltage | 23 V |
| Package | 8SOIC EP |
| Replacement Part Number | PART-MP1583DN-LF-Z |
| Weight | Contact us |
| Country of Origin | - |
