TPH4R50ANH,L1Q(M Toshiba

TPH4R50ANH,L1Q(M Images

Please contact us for more photos of TPH4R50ANH,L1Q(M

Part Number TPH4R50ANH,L1Q(M
Manufacturer Toshiba
Quantity in stock 672620 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET N-CH 100V 93A 8-Pin SOP
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level TPH4R50ANH,L1Q(M
Datasheet download TPH4R50ANH,L1Q(M.pdf
Request Quotation for TPH4R50ANH,L1Q(M

TPH4R50ANH,L1Q(M Specifications

Part Number TPH4R50ANH,L1Q(M
Supplier Package SOP
Channel Mode Enhancement
Lead Finish Tin|Silver
Channel Type N
Maximum Drain Source Voltage 100 V
Mounting Surface Mount
Product Dimensions 5 x 5 x 0.95
Typical Turn-Off Delay Time 52 ns
Maximum Gate Source Voltage ±20 V
MSL Level 1
Pin Count 8
RDS-on 4.5@10V mOhm
Screening Level Military
Typical Rise Time 9.6 ns
Typical Fall Time 13 ns
Rad Hard No
Max Processing Temp 260
Typical Turn-On Delay Time 25 ns
Operating Temperature -55 to 150 °C
Maximum Continuous Drain Current 93 A
Package 8SOP
Replacement Part Number PART-TPH4R50ANH,L1Q(M
Weight Contact us
Country of Origin -
