Please contact us for more photos of TK13A25D,S4X(S
| Part Number | TK13A25D,S4X(S |
|---|---|
| Manufacturer | Toshiba |
| Quantity in stock | 876110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 250V 13A 3-Pin TO-220SIS |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | TK13A25D,S4X(S |
| Datasheet download |  TK13A25D,S4X(S.pdf |
| Part Number | TK13A25D,S4X(S |
|---|---|
| Typical Turn-Off Delay Time | 130 ns |
| Supplier Package | TO-220SIS |
| RDS-on | 250@10V mOhm |
| Rad Hard | No |
| Operating Temperature | -55 to 150 °C |
| Max Processing Temp | 260 |
| Maximum Continuous Drain Current | 13 A |
| Typical Turn-On Delay Time | 55 ns |
| Channel Mode | Enhancement |
| Typical Fall Time | 20 ns |
| Maximum Drain Source Voltage | 250 V |
| Mounting | Through Hole |
| Product Dimensions | 10 x 4.5 x 8.1 |
| Typical Rise Time | 40 ns |
| Maximum Gate Source Voltage | ±20 V |
| Pin Count | 3 |
| Channel Type | N |
| Package | 3TO-220SIS |
| Replacement Part Number | PART-TK13A25D,S4X(S |
| Weight | Contact us |
| Country of Origin | - |
