Please contact us for more photos of STB21N65M5
| Part Number | STB21N65M5 |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 533900 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 650V 17A 3-Pin(2+Tab) D2PAK T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | STB21N65M5 |
| Datasheet download |  STB21N65M5.pdf |
| Part Number | STB21N65M5 |
|---|---|
| Channel Mode | Enhancement |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Product Dimensions | 10.4 x 9.35 x 4.6 mm |
| RDS-on | 190@10V mOhm |
| Maximum Continuous Drain Current | 17 A |
| Channel Type | N |
| MSL Level | 1 |
| Pin Count | 3 |
| Maximum Gate Source Voltage | 25 V |
| Max Processing Temp | 245|300 |
| Rad Hard | No |
| Maximum Drain Source Voltage | 650 V |
| Supplier Package | D2PAK |
| Operating Temperature | -55 to 150 °C |
| Package | 3D2PAK |
| Replacement Part Number | PART-STB21N65M5 |
| Weight | Contact us |
| Country of Origin | - |
