Please contact us for more photos of SI7820DN-T1-GE3
| Part Number | SI7820DN-T1-GE3 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 790310 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 200V 1.7A 8-Pin PowerPAK 1212 T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | SI7820DN-T1-GE3 |
| Datasheet download |  SI7820DN-T1-GE3.pdf |
| Part Number | SI7820DN-T1-GE3 |
|---|---|
| Channel Mode | Enhancement |
| Typical Fall Time | 17 ns |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Typical Rise Time | 12 ns |
| Typical Turn-On Delay Time | 11 ns |
| Maximum Continuous Drain Current | 1.7 A |
| Channel Type | N |
| Maximum Gate Source Voltage | ±20 V |
| Product Dimensions | 3.05 x 3.05 x 1.04 mm |
| Pin Count | 8 |
| MSL Level | 1 |
| Maximum Drain Source Voltage | 200 V |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Typical Turn-Off Delay Time | 30 ns |
| Operating Temperature | -55 to 150 °C |
| RDS-on | 240@10V mOhm |
| Supplier Package | PowerPAK 1212 |
| Package | 8PowerPAK 1212 |
| Replacement Part Number | PART-SI7820DN-T1-GE3 |
| Weight | Contact us |
| Country of Origin | - |
