Please contact us for more photos of PSMN2R2-40PS,127
| Part Number | PSMN2R2-40PS,127 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 318730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 40V 100A 3-Pin(3+Tab) TO-220AB Tube |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | PSMN2R2-40PS,127 |
| Datasheet download |  PSMN2R2-40PS,127.pdf |
| Part Number | PSMN2R2-40PS,127 |
|---|---|
| Supplier Package | TO-220AB |
| Typical Turn-On Delay Time | 33.2 ns |
| Channel Type | N |
| Channel Mode | Enhancement |
| Maximum Gate Source Voltage | 20 V |
| Typical Rise Time | 40.4 ns |
| Mounting | Through Hole |
| Typical Fall Time | 25.2 ns |
| RDS-on | 2.1@10V mOhm |
| Maximum Drain Source Voltage | 40 V |
| Product Dimensions | 10.3 x 4.7 x 9.4 mm |
| Operating Temperature | -55 to 175 °C |
| Max Processing Temp | 260 |
| Maximum Continuous Drain Current | 100 A |
| Rad Hard | No |
| Pin Count | 3 |
| MSL Level | 1 |
| Lead Finish | Tin |
| Typical Turn-Off Delay Time | 66.6 ns |
| Package | 3TO-220AB |
| Replacement Part Number | PART-PSMN2R2-40PS,127 |
| Weight | Contact us |
| Country of Origin | - |
