NVMFS6B14NLT3G ON Semiconductor

NVMFS6B14NLT3G Images

Please contact us for more photos of NVMFS6B14NLT3G

Part Number NVMFS6B14NLT3G
Manufacturer ON Semiconductor
Quantity in stock 166280 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET N-CH 100V 55A 5-Pin DFN T R
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level NVMFS6B14NLT3G
Datasheet download NVMFS6B14NLT3G.pdf
Request Quotation for NVMFS6B14NLT3G

NVMFS6B14NLT3G Specifications

Part Number NVMFS6B14NLT3G
Rad Hard No
Operating Temperature -55 to 175 °C
Typical Turn-Off Delay Time 14.8 ns
Moisture Sensitivity Level 1
Typical Fall Time 7.2 ns
Package Dimensions 4.9 x 5.9 x 1 mm
Channel Mode Enhancement
Screening Level Automotive
Pin Count 5
Typical Turn-On Delay Time 11 ns
Maximum Drain Source Voltage 100 V
Channel Type N
Typical Rise Time 67.6 ns
Maximum Gate Source Voltage ±16 V
Maximum Processing Temperature 260 °C
Mounting Surface Mount
Maximum Continuous Drain Current 55 A
Lead Finish Pure Tin
RDS-on 13@10V MOhm
Supplier Package DFN
Package 5DFN
Replacement Part Number PART-NVMFS6B14NLT3G
Weight Contact us
Country of Origin -
