Please contact us for more photos of NVGS5120PT1G
| Part Number | NVGS5120PT1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 106530 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET P-CH 60V 2.5A 6-Pin TSOP T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | NVGS5120PT1G |
| Datasheet download |  NVGS5120PT1G.pdf |
| Part Number | NVGS5120PT1G |
|---|---|
| Maximum Drain Source Voltage | 60 V |
| Channel Mode | Enhancement |
| Typical Fall Time | 12.8 ns |
| Typical Turn-On Delay Time | 8.7 ns |
| Max Processing Temp | 260 |
| Typical Turn-Off Delay Time | 38 ns |
| Typical Rise Time | 4.9 ns |
| RDS-on | 111@10V mOhm |
| Channel Type | P |
| Product Dimensions | 3 x 1.5 x 0.94 |
| Rad Hard | No |
| Supplier Package | TSOP |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| MSL Level | 1 |
| Maximum Gate Source Voltage | ±20 V |
| Operating Temperature | -55 to 150 °C |
| Pin Count | 6 |
| Maximum Continuous Drain Current | 2.5 A |
| Screening Level | Automotive |
| Package | 6TSOP |
| Replacement Part Number | PART-NVGS5120PT1G |
| Weight | Contact us |
| Country of Origin | - |
