Please contact us for more photos of IRFPG50PBF
| Part Number | IRFPG50PBF |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 797540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 1KV 6.1A 3-Pin(3+Tab) TO-247AC |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | IRFPG50PBF |
| Datasheet download |  IRFPG50PBF.pdf |
| Part Number | IRFPG50PBF |
|---|---|
| Channel Mode | Enhancement |
| Typical Turn-On Delay Time | 19 ns |
| Typical Rise Time | 35 ns |
| Channel Type | N |
| Maximum Gate Source Voltage | ±20 V |
| Mounting | Through Hole |
| Pin Count | 3 |
| Maximum Drain Source Voltage | 1000 V |
| Product Dimensions | 15.87 x 5.31 x 20.7 mm |
| Maximum Continuous Drain Current | 6.1 A |
| Max Processing Temp | 300 |
| RDS-on | 2000@10V mOhm |
| Supplier Package | TO-247AC |
| Operating Temperature | -55 to 150 °C |
| Rad Hard | No |
| Typical Fall Time | 36 ns |
| Typical Turn-Off Delay Time | 130 ns |
| Package | 3TO-247AC |
| Replacement Part Number | PART-IRFPG50PBF |
| Weight | Contact us |
| Country of Origin | - |
