Please contact us for more photos of FDMS86200
| Part Number | FDMS86200 |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 725500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans MOSFET N-CH 150V 9.6A 8-Pin Power 56 T R |
| Category | Discrete Semiconductor |
| Family | Transistor |
| ROHS Compliant | Yes |
| MSL Level | FDMS86200 |
| Datasheet download |  FDMS86200.pdf |
| Part Number | FDMS86200 |
|---|---|
| Maximum Drain Source Voltage | 150 V |
| Product Dimensions | 5 x 6 x 1.05 mm |
| Rad Hard | No |
| Supplier Package | Power 56 |
| MSL Level | 1 |
| Typical Rise Time | 7.9 ns |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Maximum Gate Source Voltage | ±20 V |
| Typical Turn-On Delay Time | 13 ns |
| Typical Turn-Off Delay Time | 27 ns |
| Pin Count | 8 |
| Channel Mode | Enhancement |
| Maximum Continuous Drain Current | 9.6 A |
| Operating Temperature | -55 to 150 °C |
| RDS-on | 18@10V mOhm |
| Channel Type | N |
| Typical Fall Time | 5.8 ns |
| Package | 8Power 56 |
| Replacement Part Number | PART-FDMS86200 |
| Weight | Contact us |
| Country of Origin | - |
