CSD18502Q5B Texas Instruments

CSD18502Q5B Images

Please contact us for more photos of CSD18502Q5B

Part Number CSD18502Q5B
Manufacturer Texas Instruments
Quantity in stock 300240 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Trans MOSFET N-CH 40V 26A 8-Pin VSON EP T R
Category Discrete Semiconductor
Family Transistor
ROHS Compliant Yes
MSL Level CSD18502Q5B
Datasheet download CSD18502Q5B.pdf
Request Quotation for CSD18502Q5B

CSD18502Q5B Specifications

Part Number CSD18502Q5B
Rad Hard No
Max Processing Temp 260
Typical Turn-Off Delay Time 23 ns
Maximum Continuous Drain Current 26 A
Operating Temperature -55 to 150 °C
Typical Turn-On Delay Time 5.3 ns
Typical Fall Time 4 ns
Lead Finish Matte Tin
Supplier Package VSON EP
Channel Mode Enhancement
Mounting Surface Mount
RDS-on 2.3@10V mOhm
Product Dimensions 5 x 6 x 1 mm
Maximum Gate Source Voltage ±20 V
Typical Rise Time 6.8 ns
MSL Level 1
Pin Count 8
Maximum Drain Source Voltage 40 V
Channel Type N
Package 8VSON EP
Replacement Part Number PART-CSD18502Q5B
Weight Contact us
Country of Origin -
