Please contact us for more photos of 52559-2433
| Part Number | 52559-2433 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 382920 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn FFC FPC Connector SKT 24 POS 0.5mm Solder ST SMD Embossed T R |
| Category | Connectors |
| Family | Connector FFC-FPC |
| ROHS Compliant | Yes |
| MSL Level | 52559-2433 |
| Datasheet download |  52559-2433.pdf |
| Part Number | 52559-2433 |
|---|---|
| Termination Method | Solder |
| Housing Color | Natural |
| Mounting | Surface Mount |
| Pin Count | 24 |
| Contact Gender | SKT |
| Body Orientation | Straight |
| Max Processing Temp | 250 |
| Lead Finish | Silver|Tin-Bismuth |
| Contact Plating | Silver/Tin-Bismuth |
| Product Dimensions | 17.7 x 3 x 3.9 |
| Contact Material | Copper Alloy |
| Operating Temperature | -40 to 85 °C |
| Housing Material | Polyamide |
| Rad Hard | No |
| Pitch | 0.5 mm |
| Product Depth | 3 mm |
| Product Height | 3.9 mm |
| Product Length | 17.7 mm |
| Replacement Part Number | PART-52559-2433 |
| Weight | Contact us |
| Country of Origin | - |
