Please contact us for more photos of 104083-9617
| Part Number | 104083-9617 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 749910 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn FFC FPC Connector SKT 96 POS 0.5mm Solder RA SMD Embossed T R |
| Category | Connectors |
| Family | Connector FFC-FPC |
| ROHS Compliant | Yes |
| MSL Level | 104083-9617 |
| Datasheet download |  104083-9617.pdf |
| Part Number | 104083-9617 |
|---|---|
| Contact Plating | Gold Over Nickel |
| Pitch | 0.5 mm |
| Maximum Current Rating | 0.5/Contact A |
| Number of Contacts | 96 |
| Pin Count | 96 |
| Number of Rows | 1 |
| Contact Material | Phosphor Bronze |
| Rad Hard | No |
| Lead Finish | Gold Over Nickel |
| Housing Material | Liquid Crystal Polymer |
| Max Processing Temp | 250 |
| Operating Temperature | -25 to 85 °C |
| Housing Color | Natural |
| Termination Method | Solder |
| Product Dimensions | 53.1 x 4.4 x 1.5 |
| Mounting | Surface Mount |
| Type | FFC/FPC Connector |
| Body Orientation | Right Angle |
| Maximum Contact Resistance | 40 MOhm |
| Contact Gender | SKT |
| Product Depth | 4.4 mm |
| Product Height | 1.5 mm |
| Product Length | 53.1 mm |
| Replacement Part Number | PART-104083-9617 |
| Weight | Contact us |
| Country of Origin | - |
