104026-0511 Molex

104026-0511 Images

Please contact us for more photos of 104026-0511

Part Number 104026-0511
Manufacturer Molex
Quantity in stock 713050 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conn USB Type C HDR 5 POS 0.8mm Solder RA Thru-Hole 5 Terminal 1 Port Tray
Category Connectors
Family Connector Audio and Video
ROHS Compliant Yes
MSL Level 104026-0511
Datasheet download 104026-0511.pdf
Request Quotation for 104026-0511

104026-0511 Specifications

Part Number 104026-0511
Number of Contacts 5
Housing Material Liquid Crystal Polymer
Package Dimensions 17.4 x 22.65 x 12.94 mm
Number of Terminals 5
Type USB Type C
Contact Plating Gold Over Nickel
Operating Temperature -40 to 85 °C
Contact Material Copper Alloy
Rad Hard No
Termination Method Solder
Pitch 0.8 mm
Lead Finish Tin Over Nickel
Gender HDR
Body Orientation Right Angle
Mounting Through Hole
Number of Ports 1
Product Depth 22.65 mm
Product Height 12.94 mm
Product Length 17.4 mm
Replacement Part Number PART-104026-0511
Weight Contact us
Country of Origin -
