Part Number | 0536471474 |
---|---|
Manufacturer | Molex |
Quantity in stock | 304820 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | Conn Board to Board PL 140 POS 0.635mm Solder ST SMD Embossed T R |
Category | Connectors |
Family | Connector Headers and PCB Receptacles |
ROHS Compliant | Yes |
MSL Level | 0536471474 |
Datasheet download | ![]() |
Part Number | 0536471474 |
---|---|
Mounting | Surface Mount |
Product Dimensions | 51.32 x 5.2 x 7 mm |
Pitch | 0.635 mm |
Termination Method | Solder |
Lead Finish | Tin |
Body Orientation | Straight |
Contact Material | Copper Alloy |
Housing Material | Polyphenylene Sulfide |
Operating Temperature | -55 to 85 °C |
Rad Hard | No |
Contact Plating | Gold Over Nickel |
Housing Color | Brown |
Gender | PL |
Product Depth | 5.2 mm |
Product Height | 7 mm |
Product Length | 51.32 mm |
Replacement Part Number | PART-0536471474 |
Weight | Contact us |
Country of Origin | - |
