Please contact us for more photos of 0469990566
| Part Number | 0469990566 |
|---|---|
| Manufacturer | Molex |
| Quantity in stock | 535620 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Power HDR 6 POS 4.2mm Solder ST Thru-Hole 6 Terminal 1 Port Tray |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 0469990566 |
| Datasheet download |  0469990566.pdf |
| Part Number | 0469990566 |
|---|---|
| Product Dimensions | 13.8 x 9.6 x 12.8 |
| Housing Material | Nylon 6/6 |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Lead Finish | Matte Tin Over Nickel |
| Contact Plating | Matte Tin Over Nickel |
| Termination Method | Solder |
| Pitch | 4.2 mm |
| Body Orientation | Straight |
| Mounting | Through Hole |
| Gender | HDR |
| Pin Count | 6 |
| Operating Temperature | -40 to 105 °C |
| Contact Material | Brass |
| Product Depth | 9.6 mm |
| Product Height | 12.8 mm |
| Product Length | 13.8 mm |
| Replacement Part Number | PART-0469990566 |
| Weight | Contact us |
| Country of Origin | - |
