0430451013 Molex

0430451013 Images

Please contact us for more photos of 0430451013

Part Number 0430451013
Manufacturer Molex
Quantity in stock 434450 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Conn Wire to Board HDR 10 POS 3mm Solder ST Thru-Hole Tray
Category Connectors
Family Connector Headers and PCB Receptacles
ROHS Compliant Yes
MSL Level 0430451013
Datasheet download 0430451013.pdf
Request Quotation for 0430451013

0430451013 Specifications

Part Number 0430451013
Housing Material Liquid Crystal Polymer
Contact Material Brass Alloy
Max Processing Temp 260
Contact Plating Gold Over Nickel
Termination Method Solder
Product Dimensions 19.15 x 8.77 x 9.91 mm
Operating Temperature -40 to 105 °C
Lead Finish Tin
Body Orientation Straight
Housing Color Black
Mounting Through Hole
Pitch 3 mm
Gender HDR
Product Depth 8.77 mm
Product Height 9.91 mm
Product Length 19.15 mm
Replacement Part Number PART-0430451013
Weight Contact us
Country of Origin -
